Dimensions
Height: 159 mm
Width: 12 mm
Depth: 8 mm
Weight: 20 g
Technical Specifications
Protection: 4 ft (1.2 m) drop
Power and Connectivity
-
Lithium battery
-
Up to 7 hours of active writing time
-
To turn on, slide the button down towards tip
-
After 5 seconds, lights turn off
-
When idle, the LED lights will turn on briefly to show battery life when it detects movement, transitioning from idle to active writing mode
-
Battery life indicator
-
Battery > 66%, 3 green LED
-
Battery > 33%, 2 green LED
-
Battery >15%, 1 green LED
-
Battery <15%, 1 red blinking LED
-
-
Charge via iPad USB-C cable
-
After 5 minutes of inactivity, Crayon will switch to idle mode
-
To turn off, slide button up towards charging port
-
To charge
-
Charge to 33%, 3 LED blink continuously
-
Charge to 66%, 1 LED is solid green, 2 LED blink continuously
-
Charge to 99%, 2 LED are solid green, 1 LED blink
-
Charge to 100%, 3 solid green LED
-
